Customized Single Mode Duplex Fiber Optic Patch Cord LC SC FC ST SM Fiber Patch Cable

  • 1
  • 2
  • 3

Material : High-grade optical fiber and plastic

Insertionloss : ≤ 0.2 dB

Delivery Time : 5-8 work days

Returnloss : ≥ 50 dB

Connector types : LC, SC, FC, ST

Certification : ISO9001 , ROHS

Payment Terms : L/C,T/T

Operatingtemperature : -40°C to +85°C

Name : Duplex Fiber Optic Patch Cord

Installationmethod : Plug and play, field-installable

MOQ : 1pieces

Operatingwavelength : 1260 nm to 1650 nm

Durability : Up to 1000 mating cycles

Brand Name : Gracyfiber

Place of Origin : Guangdong , China

Fiber type : Single mode

Componenttype : Optical Access

Transmission distance : Long distance

Storagetemperature : -40°C to +85°C

Productname : Optical Access Components

Application : FTTx, PON, Optical LAN, CATV

Supply Ability : 100,000 pieces per month

Signal direction : Dual-fiber (send/receive)

Cabletypecompatibility : Single-mode and multi-mode fibers

Connectortype : SC, LC, FC, ST (varies by model)

Compliancestandards : Telcordia GR-326, IEC 61754

Fiber structure : Duplex twisted pair

Core diameter : Small

Contact Now

Customized Single Mode Duplex Fiber Optic Patch Cord LC SC FC ST SM Fiber Patch Cable For Data Center Telecom Video Surveillance And Long Distance Network
Product Overview

Customized single-mode duplex fiber optic patch cords are designed for long-distance, high-bandwidth transmission.

Customized Single Mode Duplex Fiber Optic Patch Cord LC SC FC ST SM Fiber Patch Cable

Key Features
  • Single-mode, full-duplex, twisted-pair cabling
  • Insertion loss ≤ 0.2 dB
  • Return loss ≥ 50 dB
  • Operating wavelength 1260nm - 1650nm
  • Compatible with LC, SC, FC, and ST connectors
  • Industrial-grade wide operating temperature range of -40°C to +85°C
Applications
  • Data Centers
  • Telecommunications
  • FTTx & PON
  • Optical LAN
  • Video Surveillance
  • CATV


Customized Single Mode Duplex Fiber Optic Patch Cord LC SC FC ST SM Fiber Patch CableCustomized Single Mode Duplex Fiber Optic Patch Cord LC SC FC ST SM Fiber Patch Cable

FAQ

1. Which network protocols does this single-mode fiber optic patch cord support, and is it compatible with my existing equipment?

Yes. Our OS2 single-mode duplex fiber optic patch cord is designed for long-distance transmission of 10G/40G/100G and even 400G, operating at wavelengths of 1310nm and 1550nm. The product is fully compatible with switches, routers, and long-distance optical modules (such as the LR/ER/ZR series) from major manufacturers (such as Cisco, Juniper, Huawei, Arista, etc.), ensuring plug-and-play and seamless integration into your existing network architecture.

2. What are the insertion loss and return loss standards for this patch cord?

For single-mode transmission, end-face quality is crucial. We perform 100% 3D interferometer testing before shipment. The insertion loss (IL) of this single-mode patch cord is strictly controlled to ≤ 0.2 dB. Regarding return loss (RL), UPC polishing ≥ 50 dB, APC polishing ≥ 60 dB, ensuring extremely low optical signal attenuation and reflection even in ultra-long-distance trunk networks.

3. How adaptable is this product to various operating environments? Is the cable material durable?

We use high-quality G.652.D or G.657.A bend-insensitive fiber, greatly reducing micro-bending loss when cabling in confined spaces. Standard products support an industrial-grade operating temperature range of -40°C to +85°C. Outer sheath materials are available in PVC, OFNR, or Low Smoke Halogen-Free (LSZH) to meet the fire protection and environmental protection deployment requirements of different countries and regions.

4. What types of connector interface combinations do you support?

As a professional source manufacturer, we support a full range of single-mode interface combinations, including LC, SC, FC, ST, etc. You can freely combine them according to the field patch panel (ODF) or device port (e.g., LC-SC, FC-ST). High-precision ceramic ferrules ensure a stable mating life of over 1000 mating cycles.
