Single Mode Multimode Fiber Optic Patch Cord , Fiber Optic Pigtail LC/SC/FC/ST Patch Cables

Name: Single Mode Multimode Fiber Optic Patch Cord Fiber Optic Pigtail LCSCFCST Patch Cables
Brand: Gracyfiber
Price: 1 USD

Buy cheap Single Mode Multimode Fiber Optic Patch Cord , Fiber Optic Pigtail LC/SC/FC/ST Patch Cables product

Delivery Time : 5-8 work days

Tensile strength : 80N (long term), 150N (short term)

Name : Fiber Optic Patch Cord

MOQ : 1pieces

Operating temperature : -40°C to +85°C

Operating wavelength : 1260 nm to 1650 nm

Certification : ISO9001 , ROHS

Fiber core diameter : 9/125, 62.5/125, 50/125 um

Supply Ability : 100,000 pieces per month

Brand Name : Gracyfiber

Insertion loss : ≤ 0.2 dB

Payment Terms : L/C,T/T

Return loss : ≥ 50 dB

Place of Origin : Guangdong , China

Contact Now

Fiber Optic Patch Cord & Pigtail Manufacturer | LC/SC/FC/ST Patch Cables | Gracyfiber

1. Product Overview

Gracyfiber Fiber Optic Patch Cords and Pigtails provide reliable, low-loss optical connectivity for telecom, datacom, FTTx, and enterprise networks.

2. Product Features

Item	Parameters
Fiber type	G652D	G657A1	G657A2	OM1	OM2	OM3	OM4
Fiber core/cladding dia (um)	9/125			62.5/125	50/125
Fiber count	1 core or 2 cores
Material	PVC or LSZH
Color	Yellow			Orange		Aqua	Magenta
Nom. diameter (mm)	2.0, 3.0, 0.9 or others
Strength member	Kevlar
Attenuation(dB/km)	≤0.4@1310nm			≤3.0@850nm
	≤0.3@1550nm			≤1.0@1300nm
Insert loss (dB)	≤0.3
Return loss (dB)	≥50(PC)			–
	≥60(APC)			–

Structure Diagram:

Name	Description	Quantity
Fiber Connector	FC, LC, SC, ST…APC or UPC	1 or 2
Fiber Cable	G652D,G657A1,G657A2,OM1,OM2,OM3,OM4…	L (m)
Fiber Connector	FC, LC, SC, ST… APC or UPC	1 or 2

Mechanical Dimensions:

Minimum Bending Radius Cable	Dynamic	20xOD, OD=outer diameter
	Static	10xOD, OD=outer diameter
Tensile Strength		Long term tensile force: 80N
(according to IEC 60794-1-2 E1)		Short term tensile force: 150N
Crush (according to IEC 60794-1-2 E3)		Long term: 100 N/100mm
		Short term: 500 N/100mm

3. Applications

ODF
Backbone network
Data center
ONT interconnects
Telecom and FTTx networks
