14CH PM Fiber Array | 0° Flat Quartz Block, 127μm Pitch | PM II+I Alignment, Slow Axis to Key | High ER 25dB PMFA | Gracyfiber

Model Number : 910001714-01

Contact Now

1. Product Overview

This product is a 14-channel polarization-maintaining fiber array (PMFA), using quartz glass and Corning PM1550 polarization-maintaining fiber. The channel spacing is 127 μm, and the polishing angle is A0°.

2. Core Product Features

Parameters	Unit	Spec.	Value
Channel	/	24	OK
Material	/	Quartz Glass	OK
Channel Spacing	μm	127	OK
Polishing Angle	Degree	0°	OK
Package(L)X(W)X(H)	mm	125.71.5	OK
Insertion Loss	dB	≤0.3
Extinction Ratio	dB	≥18	25
FA PM Fiber Alignment	/	PMII	OK
Connctor PM Fiber Alignment	/	Slow Axis Alignment Key	OK
Fiber Type	/	PM1550(Corning)	OK
Fiber Tube	mm	0.9	OK
Tube Color	/	Blue	OK
Length	m	1±0.1	OK
Connector	/	FC/APC	OK
Operating Temperature (℃)		0～65	OK
Storage Temperature (℃)		-40～85	OK

14-channel polarization-maintaining array design
Low insertion loss performance
High extinction ratio polarization-maintaining capability
Precision FA structure design

3. Applications

1550 nm polarization-maintaining fiber communication systems
Coherent optical communication modules
Multi-channel optical modules and transceiver packaging
Silicon photonics chip coupling and photonic integration packaging
Fiber optic sensing, interferometers, and polarization control systems
Optical path coupling for lasers, modulators, and detectors
Laboratory optical path testing platforms and high-precision optical equipment
